Enviro EF-IV I User Manual

-Side wall to unit .................. E 6 INCHES (152 mm)
-Mantle to unit F 10 INCHES (254 mm)
-Top facing to unit G 8 INCHES (203 mm)
-Side facing to unit H 9 INCHES (228 mm)
-Floor protection D 6 INCHES (152 mm)
FREESTANDING PEDESTAL INSTALLATION
ASSEMBLY:
Model FS comes with a pedestal that has to be attached prior to
installation:
- Remove the pedestal from the box
- Remove the ENVIROFIRE unit from the box
- Place the ENVIROFIRE unit on its back on the
pallet.
- Back the four-(4) screws in the base off 3-4 full
turns.
- Align the keyholes in the pedestal with the
screws, lock into place.
- Secure the two pieces by tightening the four,(4)
screws from the inside of the
pedestal.
INSTALL FOUR SCREWS
HERE
18
