Enviro Evolution EF5 User Manual

2
November 2011
Installation
Dimensions – Evolution EF5 Freestanding
Installation Clearances & Specications
Minimum clearances shown are in millimetres. All Enviro res are tested to AS/NZS2918:2001.
Specications were correct at time of printing but may alter and those detailed below should be used as
a guide only. Refer to the Installation and Operation Manual supplied with every Enviro Pellet Fire or if
in doubt, consult your Switch Retailer. Refer to Safety Test 09/1981 for all clearances to combustibles.
Clearances to Combustibles
22
1
/4"
(565 mm)
34
5
/16"
(871 mm)
23
7
/16"
(595 mm)
5
5
/8"
(144 mm)
26
3
/8"
(670 mm)
28"
(711 mm)
24
3
/8"
(619 mm)
B
J
H
A
E
External Flue
J
J
F
B
I
F
E
Enviro Evolution EF5 Pellet Fire
Clearance to Combustibles
B
C
A
E
D
G
F
B
F
G
E
Internal Flue
Location
Dimension
(mm)
A 100
B 150
C* 50
D ~210
E N/A
F 75
G* 50
H 100
I* 50
J* 25
Freestanding
Clearances
* from shielded ue
Note: AS/NZS 2918
requires a minimum
of 100mm clearance
for any side requiring
access.
Note: These are
minimum clearances to
combustibles. Actual
installation distances
may be greater.
Note: The above clearance to combustibles on the ue are only applicable within the re envelope. Clearance outside this e.g.at a ceiling / wall thimble reverts to 25mm as per ARS ue
test 05/1185.
