This pellet stove requires floor protection. The floor protection must be non-combustible, extending beneath
the stove the full width and depth of the unit including 6“ (150 mm) in front for ember protection.
ALCOVE CLEARANCES - FREESTANDING:
Figure 10: Meridian on Floor
Protection.
Minimum Width
36" (914mm)
Minimum Height
48" (1219mm)
Maximum Depth
30" (762mm)
Back wall
Side wall
Adjacent
wall
2"
(51mm)
3" (76mm)
6"
(152mm)
Installation
CLEARANCES TO COMBUSTIBLES - FREESTANDING:
These dimensions are minimum clearances but it is recommended that you ensure sufficient room for
serving, routine cleaning and maintenance.
Figure 11: Minimum Clearances to Combustibles for
Freestanding Meridian.
Figure 12: Alcove Clearances Freestanding Meridian.
13
