Enviro PRO-CS-1344 User Manual

Enviro Water Products Pro Series Water Filter and Salt Free
Softening Systems
© 2014 Enviro Water Solutions LLC
3060 Performance Circle, Suite 2. DeLand, FL 32724
Rev B
Page 9
www.envirowaterproducts.com
Installation
Pre-Filter Assembly
Figure 5
1. Unscrew the cover from the Blue Pre-Filter Housing.
2. Remove the plastic covering from the Sediment Filter.
3. Place the Sediment Filter onto the Stand Pipe in the Blue Pre-Filter Housing.
4. Screw the cover onto the Blue Pre-Filter Housing until hand-tight.
Pre-Filter Installation
Figure 6
1. Shut off the water.
2. Attach the Mounting Bracket to the wall using the supplied Phillips Head Screws and Washers.
3. Attach the Pre-Filter System to the Mounting Bracket using the supplied Bolt Head Screws.
4. Lube the o-ring with clean silicone grease before attaching the cover onto the housing.
5. Tighten the Blue Pre-Filter Housing using the supplied Pre-Filter Wrench (counter clockwise).
6. Determine the size of your inlet water supply line. PVC Reducers may be needed to fit the 1” Pre-
Filter System.
Notice:
The Pre-Filter Housing comes with a 1” threaded female inlet/outlet and will require additional fittings to
adapt to your plumbing. A shut-off valve is recommended prior to the Pre-Filter System.
Pre-Filter Cover
Sediment Filter
O-Ring
Stand Pipe
Blue Pre-Filter Housing
Top View Pre-Filter
Blue Pre-Filter Housing
Inlet Water
Supply
Mounting
Bracket
