SimpleDist® Micro Heating Block: Operation & Instruction Manual Getting Started
Unpacking
1. Remove the SimpleDist® Micro Heating Block from the shipping container by lifting from the
bottom of the block. The lid should not be used for lifting.
2. Your SimpleDist® Micro Heating Block is shipped with metal screws securing the bottom panel.
The metal screws must be removed before operating your SimpleDist® Micro Heating Block.
Remove the metal screws and replace them with the PVC screws and rubber feet included with
your shipment. The corrosion-resistant PVC screws and rubber feet are designed to secure the
bottom plate.
Important: Do not overtighten the PVC screws!
3. Disposable distillation tubes are not included with the SimpleDist® Micro Heating Block.
Order tubes separately on page 20.
4. Save original packaging material in a dry area for use if unit needs to be returned for service.
Refer to warranty policy on page 1.
Installation Requirements
Locate the SimpleDist® Micro Heating Block under a fume hood with a minimum face velocity
of 100 CFM, and allow a minimum of 2” of space on all sides. The following environmental
conditions should be observed:
Ambient temperature range: 5 to 30°C
Ambient relative humidity: 0 to 90%RH
Altitude: sea level to 2500 meters
This product is rated as Pollution Degree 2 and Installation Category 2.
Electrical Requirements
Required Voltage: 120 volts, ~60 Hz, 15 A
(Also available in 240 VAC)
Power should not vary greater than ±10%. Use the supplied heat-resistant power cord or
equivalent to connect to the power supply.
For safety reasons, a separate power receptacle should be provided for each unit in the system.
Do not use extension cords or outlet adaptors. Make certain that power outlets are earth-
grounded at the grounding pin.
See individual specications for each SimpleDist® Micro Heating Block model.
