Envision LCD User Manual

10
TECHNICAL SPECIFICATIONS
LCD panel
Contrast ratio
Viewing angle
Response time
Brightness
Input signal
Display colors
Synchronization
Recommended
Resolution
Supported
Resolutions
Power
consumption
Dimensions
Weight
Environmental
19 wide diagonal size
500:1 (typical)
horizontal 140°, vertical 130° (typical)
8ms (typical)
300 cd/㎡ (typical)
Video: analog (D-SUB)
16.2 mill. Colors
31~ 81 kHz horizontal, 56 ~ 75 Hz vertical
1440×900/60Hz
640x480/60Hz; 640x480/67Hz; 640x480/73Hz; 640x480/75Hz;
720x400/70Hz; 800x600/56Hz; 800x600/60Hz; 800x600/72Hz;
800x600/75Hz; 832x624/75Hz; 848x480/60Hz; 1024x768/60Hz;
1024x768/70Hz;1024x768/75Hz;1028x1024/60Hz;1028x1024/75Hz;
1152x864/75Hz;1280x720/60Hz; 1280x768/60Hz; 1280x768/75Hz;
1360x768/60Hz; 1440x900/60Hz;
Input: 100-240 V+/-10%AC-CD, 50/60 Hz
ON status: max.50 W; color of the status LED: green
SLEEP status: <1.5 W; color of the status LED: amber
Power saving functions EPA certified
Width: 446 mm, height: 375 mm, depth: 178 mm
4.6KG(Net) 6.7 kg (Gross)
Operation:
5 - 35 , humidity:20 ℃ - 90% (without condensation)
Storage:
-20- +60 , humidity:5 ℃ – 90% (without condensation)
***The above specification is subject to actual panel specification and is subject to
change without prior notice.
