ENVO D35 | ST EBIKE MANUAL | VERSION 1.0 24
Figure 4I
Figure 4J
Figure 4K
4.5.3. ENVO ST HANDLEBAR ASSEMBLY
• Remove the two Allen bolts on the handlebar to loosen it up
Figure 4I
• Place the handlebar onto the headset and tighten the bolts
• Adjust the handlebar height by loosening and or tightening
the clamp Figure 4J
• You can also adjust the angle of the handlebar when the
clamp is loosened Figure 4K
