ENVO D35 | ST EBIKE MANUAL | VERSION 1.0 25
4.5.4. LAMP AND FRONT FENDER MOUNTING
• Remove the Allen bolt Figure 4L
• Place the fender with the lamp behind the fork bridge,
and screw them into place Figure 4M, Figure 4N
• Take out the clamps that are provided in the small box
• Put the clamp on the fork and fender, align the holes and
pass the bolt through
• Put the nut with the washer on the bolt and tighten.
You may need a size 8mm wrench to hold the nut for
tightening Figure 4O
• Repeat steps for the other side
4.5.5. FENDER & RACK MOUNTING
• The rack and rear fender comes preassembled
• It is a good practice to check if all the fasteners are
tightened
Figure 4L
Figure 4M
Figure 4N
Figure 4O
