· An AMBIENT FLOW FAULT is logged when flow rate through the ambient air intake falls
below the ambient low flow limit or climbs above the ambient high flow limit.
· A GENERATOR FLOW FAULT is logged when flow rate through the generator air intake
falls below the generator low flow limit or climbs above the generator high flow limit.
· A VACUUM FAULT is logged when the Vacuum level or the duty cycle of the Vacuum
pump deviates from its normal range.
· A PHOTOCELL FAULT is logged when the LED current deviates from its normal range.
The normal range of LED current is from 4 mA to 16 mA.
· A CYCLE FAULT is logged when the timing of the vacuum pulse varies by more than 2
percent.
· A WATER FAULT is logged when the GCM-A is low on water or when it uses an unusual
amount of water. An unusual amount is defined as filling for more than 15 continuous
seconds or going without water for more than 24 hours.
About the Power Log
· The Power log records the minimum and maximum voltage of each power supply. The
voltage is sampled once every two seconds.
· When SHOW POWER LOG is selected, the GCM-A will display the minimum and
maximum for each power supply in the format <nominal value>=<minimum
value>,<maximum value>. An example for the 5-volt power supply is +5V=4.9,5.2. Use
the UP ARROW key or DOWN ARROW key to scroll through the five power supply
voltages. Press the FN key to return to the LOG MENU.
(About the Faults Log, cont’d)
