REV. 09/2020
B6
1.Key switch A
Connect and interrupt control current.
• When the key rotates to gear “OFF”, the
control current of the truck will be interrupted;
• When the key rotates to gear “ON”, the
control current of the truck will be connected.
1.1.3 Key switch
EPL151
/
EPL154/EPL185
HPL152
Lowering lever
Power switch button
"Horn" button
Emergency reverse switch
Drive switch
Pull and hold the manual lower switch (2).The
forks will lower to the minimum height until they
stop by themselves.
Start the truck
Activates the horn.
Press the emergency reverse switch. The
vehicle will begin to travel in the opposite
direction.
Select the required driving direction and speed.
3.Control handle C
