REV. 12/2020
6B
The LCD display (2) show battery remaining charge.
When the truck has been released via the key switch, the battery charge status is displayed.
The color of the LCD (2) represent the following conditions:
LCD color Remaining charge capacity
(reference value)
Green 70-100%
Orange 30-60%
Flashing Red 0-20%
If remaining battery capacity is below 30%, A ashing red LCD shows warning.
If remaining battery capacity is below 20%, Two ashing red LCDS show warning, And lifting is now
prohibited. The battery must be charged.
The battery discharge indicator has a memory function, it can remember the battery power after the
power is turned o, and next time when it is turned on, it will show the power in it’s memory.
If you want to reset battery discharge indicator, please turn on the key after properly charging.
