ep EST122 - Key Switch; Display Instrument

REV. 12/2020
5
B
1.Key switch
Connect and interrupt control current.
When the key rotates to gear “OFF”, the
control current of the truck will be interrupted;
When the key rotates to gear “ON”, the
control current of the truck will be connected.
2.2.2 Key switch
2.2.3 Display instrument
Fig0000-00070OM
LED (1) displays the remaining electric of the
battery;
LCD (2) displays the total operation time of
the truck;
LCD (3) is a fault indicating light.
DISPLAY DESCRIPTION
Continuous red Normal
Flashing Truck failure.
Refer to relevant descriptions in “discharge
indicator and hour meter” for the display
functions of LED (1).
i
Truck failure is in the service manual
controller error message section.
NOTE
Fig2108-00018OM
