Epever MT Series - Auto global view mode

10
 RS485communicationport
It is used to connect the controller which Power the MT11.
 Communicationcable’s models
CC-RS485-RS485-3.81-4P-150(Included)
CC-RS485-RS485-3.81-4P-1000(Optional)
CC-RS485-RS485-3.81-4P-2000(Optional)
 Pins definition
PIN
Definition
1
DC5V
2
RS-485-B
3
RS-485-A
4
GND
