Low Voltage Reconnect Voltage
Under Voltage Warning Reconnect
Voltage
Under Volt. Warning Voltage
Low Volt. Disconnect Voltage
The following rules must be observed when modifying the parameter values
in User for the lithium battery.
A.Over Voltage Disconnect Voltage>Over charging protection
voltage(Protection Circuit Modules(BMS))+0.2V
※
;
B.Over Voltage Disconnect Voltage>Over Voltage Reconnect Voltage=
Charging Limit Voltage ≥ Equalize Charging Voltage=Boost Charging
Voltage ≥ Float Charging Voltage>Boost Reconnect Charging Voltage;
C.Low Voltage Reconnect Voltage>Low Voltage Disconnect Voltage ≥
Discharging Limit Voltage;
D.Under Voltage Warning Reconnect Voltage>Under Voltage Warning
Voltage≥ Discharging Limit Voltage;
E.Boost Reconnect Charging voltage> Low Voltage Reconnect Voltage;
F.Low Voltage Disconnect Voltage ≥ Over-discharging protection voltage
(BMS)+0.2V.
WARNING:The voltage parameters of the lithium battery can be set,
but you must refer to the voltage parameters of lithium battery BMS.
