11
Toilet installation
Toilet drain
outlet
Sealing flange
Mark the center line of the sewage outlet
on the ground, and install a three-way
angle valve at a suitable position on the
wall according to the size of the toilet.
Install the matching three-way angle
valve
1.
Line
Drain outlet
Equipped with three-way angle valve
305mm
2.
Drain outlet
Rough-in template installation
Align cardboard with the centerline of
drain outlet.
Draw contour line according to cardboard.
3.
Nut
Bolt
Mounting bracket installation
Assemble the mounting bracket with bolts
and then install them to the pre-installed
flange plate on the ground and lock tight
with nuts.
Mounting bracket
Washer
4. Ceramic toilet installation
Install a sealing flange into drain outlet.
Install ceramic toilet on the corresponding
position.
1.
2.
3.
Note:
Two people are required to carry the toilet.
Please clean up the drain outlet.
Please make sure ceramic toilet outlet sits
perfectly on drain outlet.
1.
2.
Note:
Please use the supplied angle valve when
installing this toilet. Use of another angle
valve not including a filter may result in
blockages in the toilet and bidet
waterways.
If replacing an existing angle valve, please
contact a professional for installation.
Installation Method 1:
NPT 1/2
Installation Method 2:
To Next Page
