EE33 Humidity / Temperature Sensor for High Humidity and Chemical Applications
Enclosure material / Protection rating Polycarbonate / IP65 / NEMA 4X
AlSi
9
Cu
3
/ IP65 / NEMA 4
Probe material Stainless steel 1.4404
Cable gland M16x1.5 cable Ø4.5 - 10 mm
(0.18 - 0.39")
Electrical connection
Screw terminals max. 1.5 mm² (AWG 16)
Electromagnetic compatibility EN 61326-1 EN 61326-2-3
Industrial Environment
FCC Part15 Class A ICES-003 Class A
Storage conditions without display -40...60 °C
(-40...248 °F), non-condensing
with display -20...50 °C
(-4...122 °F), non-condensing
Configuration and adjustment EE-PCS (Product Configuration Software, free download)
and configuration cable HA010304
1) Traceable to international standards, administrated by NIST, PTB, BEV... The accuracy statement includes the uncertainty of the factory calibration
with an enhancement factor k=2 (2-times standard deviation). The accuracy was calculated in accordance with EA-4/02 and with regard to GUM
(Guide to the Expression of Uncertainty in Measurement)
2) Appropriate for outdoor use, wet location, degree of pollution 2, overvoltage category II, altitude up to 3 000 m (9 843 ft).
3) USA & Canada: class 2 supply required.
Working Range Humidity Sensor
The grey area shows the allowed measurement range for the
humidity sensor.
Operating points outside of this range do not lead to destruction
of the sensor, but the specified measurement accuracy cannot
be guaranteed.
RH [%]
T [°C]
