SKE8-12-15-20
GB-0305.1
Date:
Signed:
11 Coupling 100 h Check that the ratchet is
working freely, alternatively
clean and grease all parts.
When the spreader is con-
nected, the ratchet cham-
ber, ratchet holder and rat-
chet must move freely
without touching the scra-
per. When the speeder is
disengaged, the ratchet
must be fully compressed.
12 Pawl for clutch Lubricating oil 100 h
13 Strickler Lubricating oil 100 h
14 Clutch lever Lubricating oil 100 h
15 Eccentric Lubricating oil 100 h
16 Stabiliser and support leg Lubricating oil 100 h
17 Nuts for drawbar *120 Nm (12,0 kpm) Before *Torque moment
each season
18 Greasing bearing Ball bearing grease Before
(drive wheel axle) each season
19 Salt spreading During longer It is recommended that the
pauses in spreader be flushed with
spreading water.
To be checked
Pos.
Machine:
Inspection list - mechanical
Measure size
and test size.
Operational
means and con-
sumption means
Interval Result of
inspection
Comment
6.3.1.
