SKE8-12-15-20
GB-0305.1
Date:
Signed:
1 Flanged bearings:
At the delivery roller and
the impellor shaft Ball bearing grease 25 h
2Tallow string packing:
At the delivery roller and
the impellor shaft 25 h ***
3 Delivery roller:
Cams 50 h Visual inspection. Worn
cams to be replaced.
4 Impellor springs 50 h Worn springs to be replaced
5 Rubber bases 50 h The rubber bases are wed-
ged in under the clamping
iron and can be turned and
worn on all edges - provided
that they are turned in time.
6 Spring base 50 h Visual inspection. When
the spring base is wide
open, the points of the
springs must be in line.
Worn springs to be replaced
7 Chain transmission:
Roller chains 50 h Check that the chains are
tight. The chains must not,
however, be firmly tightened.
Rolling chain - lubrication Wynn's Viscotene 50 h Silicone spray grease
8 Wheel nuts *140 Nm (14,0 kpm) 50 h *Tightening moment
9 Air pressure see tyre list 50 h
10 Spring base adjustment Grease 100 h
*** The tallow string packing consists of a rubber collar in which the tallow string of 2 1/2 windings is pressed in between
flange bearing and covering plate. When the flange bearing is mounted, the space between tallow string and flange
bearing is filled withe grease, which supports the tightening effect of the tallow string. Lubrication is carried out with
intervals of 25 hours of operation. If the grease penetrates into the hopper through the tallow string packing when lubrica-
ting, the tallow string should be replaced.
To be checked
Pos.
Machine:
Inspection list - mechanical
Measure size
and test size.
Operational
means and con-
sumption means
Interval Result of
inspection
Comment
6.3.1.
