SKE8-12-15-20
GB-0305.1
Tested
Inspection
Draw bar
Control at use (Visual inspection)
Date
Signed
Result Date Signed
• TThe drawbar is adjustable in height.
Important: When adjusting height, self-locking nuts must only be used once, i.e. always use new self-locking nuts. Nut
(M14 DIN 985 A2) torque is 120 Nm.
• Do not perform subsequent changes on the drawbar, e.g. welding repairs.
• Check the driving gear for wear at regular intervals.
• Replace the bush at the “eye”. The bush may be replaced by rolling or pressing it in. Do not insert a bush by welding
or tacking.
7.1.12
