Installation
Centrifuge 5424/5424 R
English (EN)
4 Installation
4.1 Selecting the location
Select the location for the device according to the following criteria:
• Suitable power connection as per the name plate (230 V/120 V/100 V).
• Stable, horizontal and resonance-free lab bench.
• A well ventilated environment which is protected from direct sunlight to prevent the device from heating
up more.
4.2 Preparing installation
Prerequisites
The weight of the Centrifuge 5424/5424 R is 13.4 kg or 21 kg . For unpacking and installing the Centrifuge
5424/5424 R, you require the assistance of another person.
Perform the following steps in the sequence described.
1. Open the packaging board.
2. Remove accessories.
3. Reach with your hands under the device and lift the centrifuge from the carton with another person.
4. Remove the front and back transport protection pads.
5. Place the device on a suitable lab bench.
6. Remove the plastic sleeve.
NOTICE! If an error occurs, the objects in the immediate proximity of the device will be
damaged.
In accordance with recommendations in EN 61010-2-020, leave a safety clearance of 30
cm around the device during operation.
Please remove all materials and objects from this area.
NOTICE! Damage from overheating.
Do not install the device near heat sources (e.g. heating, drying cabinet).
Do not expose the device to direct sunlight.
Ensure unobstructed air circulation. Maintain a clearance of at least 30 cm around all
ventilation grilles.
