15
Product description
Concentrator plus/Vacufuge® plus
English (EN)
2.4.3 Special information for individual rotors
Rotor F-45-72-8 and Rotor F-45-48-11
•You can place two of these rotors on top of each other by using a spacer (order no. Int.: 5301 316.005 /
North America: 022822101) and centrifuge them at the same time.
Included with the accessories are rotor feet which can be screwed to the corresponding bores in the
rotor. Their purpose is to prevent the samples from being pushed out of the bores when the rotor is put
down on the work bench. The rotors can be centrifuged with the rotor feet. The screws must be checked
monthly and re-tightened if required.
•For this combination, lower upper limits apply for the maximum load: Bottom rotor: ⅔ of the max. load,
top rotor ⅓ of the max. load.
Rotor F-45-24-12
•Tube length ≤ 75 mm: max. capacity 24 tubes.
•Tube length > 75 mm: max. capacity 12 tubes.
Rotor A-2-VC
•Tubes, PCR strips and plates without border can only be used with a suitable work plate (see Adapters
on p. 59).
•Max. loading height: 27 mm.
Rotor F-35-6-30
•The recommended maximum filling volume for 50 mL conical tubes is 44 mL. If the tubes are filled up
to the top, samples may spill due to the rotational movement.
