epro CON 011 - Environmental Conditions

Page 13
Direction for Use (GB) / Gebrauchsanleitung (D)
Converter CON 011
Direction for use
Absolute Linearity errors for extended measuring ranges (CON 011 / 91x−xxx):
Sensor type / Meas. ranges CON−version Linearity error GAP
PR 6422 MB: 1,5 mm
PR 6423 MB: 3,0 mm
PR 6423 MB: 4,0 mm
PR 6424 MB: 6,0 mm
PR 6424 MB: 8,0 mm
PR 6424 MB: 10,0 mm
PR 6425 MB: 4,0 mm
PR 6425 MB: 6,0 mm
PR 6425 MB: 8,0 mm
PR 6425 MB: 10,0 mm
PR 6426 MB: 12,0 mm
PR 6426 MB: 16,0 mm
PR 6426 MB: 20,0 mm
PR 6426 MB: 24,0 mm
912 – 015
913 – 030
913 – 040
914 – 060
914 – 080
914 – 100
915 – 040
915 – 060
915 – 080
915 – 100
916 – 120
916 – 160
916 – 200
916 – 240
±2,00 %
±1,50 %
±2,00 %
±1,00 %
±1,50 %
±2,00 %
±1,50 %
±2,00 %
±3,00 %
±4,00 %
±1,50 %
±2,00 %
±2,50 %
±3,50 %
0,60 mm
0,80 mm
1,00 mm
0,70 mm
0,70 mm
0,60 mm
1,00 mm
1,00 mm
1,00 mm
1,00 mm
1,50 mm
1,50 mm
1,50 mm
1,50 mm
1.5.5 Environmental conditions
Temperatures:
− Reference value +23°C
− Nominal operating range −30.... +100°C
− Limit range for operating −40.... +105°C, only for non−Ex−i applications
− Storage and transport −40.... +105°C
Humidity IP 67: 300mm water depth for max. 24h
Vibration 10...60 Hz with a = 0,35mm
according to IEC 68−2−6 60...150 Hz with 5g constant
Shock 40g for 6ms according to IEC 68−2−29
CE – compatibility Test according to:
EN 55011(1998) & A1(1999) & A2(2001)
(emitted interference)
EN 61362(1997) & A1(1998) & A2(2001) & A3(2003)
(interference resistance)
Housing
− dimensions (mm) (Fig 8) 59 x 75x 100 ( height x width x length )
− material GD − Al Si 8 Cu 3
− mounting with 4 screws M5
Weight 0.6 kg net weight, 0.68 kg with packing
Accessories 4 mounting screws (socket−head cap) M5 x 20 (DIN
912) with washers and lock washers
