12
Environmental parameters
Environmental parameters Parameter
Working temperature
-35℃ to +50℃
Storage temperature
-35℃to +80℃
Humidity ≤95% NC
Enclosure IP30
LS1024B Mechanical parameters
Mechanical Parameter Parameter
Overall dimension
138.6(5.46)x69.3(2.73)x37(1.46)
mm/inches
Mounting dimension 126(4.96) mm/inches
Mounting hole size Φ4.3
Terminal 4mm
2
Net weight 0.13kg
LS2024B Mechanical parameters
Mechanical Parameter Parameter
Overall dimension
159.6(6.28)x81.4(3.2)x47.8(1.88)
mm/inches
Mounting dimension 147(5.79)x50(1.97) mm/inches
Mounting hole size Φ4.3
Terminal 10mm
2
Net weight 0.3kg
LS3024B Mechanical Parameters
Mechanical Parameter Parameter
Overall dimension
200.6(7.9)x101.3(3.99)x57(2.24)
mm/inches
Mounting dimension 190(7.48)x70(2.76) mm/inches
Mounting hole size Φ4.5
Terminal 10mm
2
Net weight 0.5kg
