Turning and Tilting the DM-D5 0 0
You can turn or tilt the display while holding the support. The display
can be moved easily, so do not move any further if it stops. If you move
it by force, you may damage it.
With the “DM-D pole unit for IR” (DP-504) and the “DM-D pole unit
for TM printers (Type B)” (DP-503), the display area maynot face the
direction you desire. In this case, remove the base, change the position
of the tab ob the base so that the display faces to the direction you
desire, and reattach it to the base.
The display area has the following range of movement:
❏ Tilt: 48° max. (4 steps, 5 positions)
❏ Horizontal rotation: 90° max. (45° for each left and right)
45° for left
(you can turn the same angle for right.)
48°
