Epson 201 - Electrical Specifications; Environmental Specifications

39
Engli
s
h
❏ Tilt angle Max 48° (4 steps, 5 positions)
❏ Horizontal rotation
Max 90° (for each left and right at 45°)
❏ Vacuum fluorescent display
• Total number of dots: 256 (W) × 64 (H) dots
• Dot pitch: 0.55 × 0.55 mm
• Number of characters: 32 column × 4 lines max.
(When using Font A)
• Number of characters: 42 column × 8 lines max.
(When using Font B)
• Display color: Green (505 nm)
• Brightness: 300 (cd/m
2
)
Electrical Specifications
❏ Type PS-170, PA-6508, PB-6509, PB-6510,
PA-6511, PA-6513 (when using the DM-D stand)
❏ Rated voltage DC 11.4 to 48 V
❏ Rated current 0.53 A (at 11.4V) (max.)
Environmental Specifications
❏ Operation environment
Temperature: 5°C to 40°C
Humidity: 30% to 85% (No condensation)
❏ Storage environment
Temperature: −10°C to 50°C
Humidity: 30% to 90% (No condensation)
