Epson 810 - Projector Parts

8 Introduction
Projector Parts
Control panel
Ventilation slots
Lens cover
Vertical lens shift dial
Adjustable foot
Video port
HDMI port
Component
AC power inlet
Infrared
receiver
Kensington
®
lock port
Infrared receiver
D/SCART port
(used mainly in
Japan)
Horizontal lens shift dial
S-Video port Control (RS-232C) port
Trigger out
port
PC
Zoom ring
Focus ring
Main power switch
