About DuoLink
DuoLink is a BrightLink feature that lets you draw seamlessly across the projected images of two
adjacent projectors. This guide explains how to set up your computer and two BrightLink projectors to
use DuoLink.
This guide is intended for use with the following BrightLink projectors:
• BrightLink 685Wi
• BrightLink 685Wi+
• BrightLink 695Wi
• BrightLink 695Wi+
• BrightLink 696Ui
• BrightLink 697Ui
• BrightLink 710Ui
• BrightLink Pro 1450Ui
• BrightLink Pro 1460Ui
• BrightLink Pro 1470Ui
Note: The illustrations and screen captures in this guide are intended only for representative purposes.
While the specific items shown may not be identical to the ones on your product, the steps are the same
unless stated otherwise.
Note: The BrightLink 685Wi and BrightLink 685Wi+ projectors do not support finger touch. If you are
installing these models, please ignore any touch-specific instructions.

Epson BrightLink 685Wi Specifications

General

Matrix size	0.59 \
Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	- m
Projection technology	3LCD
Contrast ratio (dynamic)	14000:1
Contrast ratio (typical)	300:1
Screen size compatibility	60 - 100 \
Projection distance (tele)	0 - 0.6 m
Projection distance (wide)	0 - 0.4 m
Projector native resolution	WXGA (1280x800)
Vertical synchronization (max)	0.12 kHz
Vertical synchronization (min)	0.1 kHz
Keystone correction, horizontal	±3 °
Projector brightness (economic mode)	2900 ANSI lumens
Focus	Manual
Throw ratio	0.28:1
Digital zoom	1.35 x
Focal length range	- mm
Lamp power	250 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Microphone in	Yes
Composite video in	1
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	0
Wi-Fi	-
Noise level	35 dB
Noise level (economic mode)	29 dB
RMS rated power	16 W
Placement	Wall
Product type	Short throw projector
Product color	Grey, White
Market positioning	Short throw
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2.2 W
Power consumption (typical)	373 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	400 mm
Width	367 mm
Height	149 mm
Weight	5900 g
