Attaching to the DM-D Stand
The DM-D500 can be attached directly to the DM-D stand using the
“DM-D stand unit for DM-D500” (DP-501). The DM-D500 with the
DM-D stand can be connected to a TM printer or be used as a
standalone product.
Required items
The items shown in illustration 52, 53, or 54 are used to attach the
DM-D500 to the DM-D stand. Note that an optional power unit
(PS-180) is required when using the DM-D stand. Also, another
optional extension support (DP-105) is required if you want to raise
the height of the DM-D500. Get them separately from the DM-D
stand unit (DP-501).
<DM-D stand unit for DM-D500 (DP-501)>
DM-D stand base plate
extension cable
for power supply
RS-232 connector
installation screw (mm type)
52
53 54
<extension support (DP-105)>
Velcro tapes
extension
support
power supply
unit (PS-180)
AC cable
