Epson EB-1785W User Manual

Copying Menu Settings Between Projectors (Batch Setup)
138
g
Connect the USB flash drive containing the saved batch setup file to the
projector's USB-A port.
h
Hold down the [Menu] button on the remote control or the control
panel and connect the power cord to the projector.
i
When all of the projector's indicators turn on, release the [Menu]
button.
When all of the indicators start flashing, the settings are being written.
When writing is finished, the projector turns off.
Caution
Do not disconnect the power cord or the USB flash drive from the projector
while the file is being written. If the power cord or drive is disconnected,
the projector may not start correctly.
j
Remove the USB flash drive.
Transferring Settings From a Computer
You can copy menu settings from one projector to another of the same model
by connecting the computer and projector with a USB cable.
a
You can use this batch setup method with the following operating
system versions:
• Windows Vista and later
• OS X 10.7.x and later
a
Disconnect the power cord from the projector, and check that all of the
projector's indicators have turned off.
b
Connect a USB cable to the computer's USB port and to the projector's
USB-B port.
c
Hold down the [Esc] button on the remote control or the control panel
and connect the power cord to the projector.
d
When all of the projector's indicators turn on, release the [Esc] button.
The computer recognizes the projector as a removable disk.
e
Open the removable disk icon or folder, and save the batch setup file to
the computer.
a
The file name for the batch setup file is PJCONFDATA.bin. If
you need to change the file name, add text after PJCONFDATA
using only alphanumeric characters. If you change the
PJCONFDATA section of the file name, the projector may not be
able to recognize the file correctly.
f
Eject the USB device (Windows) or drag the removable disk icon to the
Trash (OS X).
g
Disconnect the USB cable.
The projector turns off.
h
Disconnect the power cord from the projector to which you want to
copy settings, and check that all of the projector's indicators have
turned off.
i
Connect the USB cable to the computer's USB port and to the
projector's USB-B port.
j
Hold down the [Menu] button on the remote control or the control
panel and connect the power cord to the projector.
k
When all of the projector's indicators turn on, release the [Menu]
button.
The computer recognizes the projector as a removable disk.

Epson EB-1785W Specifications

General

Matrix size	0.59 \
Number of colors	1.073 billion colors
Native aspect ratio	16:10
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	10000:1
Screen size compatibility	30 - 300 \
Projection distance (tele)	0.8 - 8.2 m
Projection distance (wide)	0.7 - 6.8 m
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	-20 - 20 °
Projector brightness (economic mode)	1900 ANSI lumens
Noise level	39 dB
Password protection	Yes
Noise level (economic mode)	30 dB
Throw ratio	1.04 - 1.26:1
Focal length range	13.52 - 16.22 mm
Aperture range (F-F)	1.58 - 1.7
RMS rated power	1 W
Number of built-in speakers	1
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black, White
Cable lock slot type	Kensington
Lamp power	214 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	7000 h
Built-in display	-
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.34 W
Power consumption (typical)	295 W
Power consumption (economy mode)	208 W
3D	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
USB 2.0 ports quantity	2
Component video (YPbPr/YCbCr) in	0
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Standard interfaces	HDMI, NFC, USB, VGA, Wireless LAN
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA

Weight and Dimensions

Depth	213 mm
Width	292 mm
Height	44 mm
Weight	1800 g
