Epson EB-735Fi User Manual

Contents
2
Notations Used in This Guide 8
Using the Manual to Search for Information .................................. 9
Searching by Keyword................................................................................................................... 9
Jumping Directly from Bookmarks............................................................................................ 9
Printing Only the Pages You Need............................................................................................ 9
Getting the Latest Version of the Documents............................... 10
Introduction to Your Projector 11
Projector Features............................................................................ 12
Long-life Laser Light Source...................................................................................................... 12
Unique Interactive Functions.................................................................................................... 12
Quick and Easy Setup .................................................................................................................. 13
Flexible Connectivity.................................................................................................................... 13
Connect with Computers ..................................................................................................... 13
Connect with Mobile Devices............................................................................................. 14
Projecting for Exhibitions........................................................................................................... 14
Projector Parts and Functions ........................................................ 16
Projector Parts - Front/Side ....................................................................................................... 16
Projector Parts - Top/Side .......................................................................................................... 17
Projector Parts - Rear.................................................................................................................... 18
Projector Parts - Base ................................................................................................................... 19
Projector Parts - Control Panel................................................................................................. 20
Projector Parts - Remote Control ............................................................................................ 21
Projector Parts - Interactive Pens ............................................................................................ 23
Projector Parts - Pen Stand........................................................................................................ 24
Projector Parts - Touch Unit ...................................................................................................... 25
Safety Instructions for Magnet................................................................................................. 26
Setting Up the Projector 27
Projector Placement ........................................................................ 28
Projector Setup and Installation Options............................................................................. 29
Settings when Using the Interactive Features ................................................................... 30
Settings when Using the Touch Unit............................................................................... 31
Projector Connections ..................................................................... 32
Connecting to a Computer........................................................................................................ 32
Connecting to a Computer for VGA Video and Audio.............................................. 32
Connecting to a Computer for USB Video and Audio............................................... 33
Connecting to a Computer for HDMI Video and Audio ........................................... 34
Connecting to a Mini PC Installed on a Wall Plate...................................................... 34
Connecting a Computer for Use with PC Interactive Features.............................. 35
Connecting to Video Sources ................................................................................................... 36
Connecting to an HDMI Video Source ............................................................................ 36
Connecting to a Composite Video Source..................................................................... 37
Connecting to External USB Devices ..................................................................................... 37
USB Device Projection ........................................................................................................... 37
Connecting to a USB Device ............................................................................................... 38
Disconnecting a USB Device ............................................................................................... 38
Connecting to a Document Camera ...................................................................................... 39
Connecting a Printer .................................................................................................................... 39
Connecting to External Devices............................................................................................... 39
Connecting to a VGA Monitor ............................................................................................ 39
Connecting to External Speakers ...................................................................................... 40
Connecting a Microphone ................................................................................................... 41
Connecting Multiple Projectors of the Same Model ....................................................... 41
Installing Batteries in the Remote Control.................................... 44
Installing Batteries in the Pens....................................................... 45
Remote Control Operation.............................................................. 46
Using Basic Projector Features 47
Turning On the Projector ................................................................ 48
Home Screen................................................................................................................................... 49

Epson EB-735Fi Specifications

General

Matrix size	0.61 \
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	- m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 100 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	2500 ANSI lumens
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Focus	Manual
Throw ratio	0.26 - 0.36:1
Fixed focal length	3.7 mm
3D	No
Full HD	Yes
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
Audio (L/R) out	1
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	36 dB
Country of origin	China
Interactive input supported	Interactive pen/Touch
Noise level (economic mode)	26 dB
Cables included	AC
Bundled software	Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projektor Management
Storage temperature (T-T)	-10 - 60 °C
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	255 W
Power consumption (economy mode)	197 W
Placement	Ceiling, Wall
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
RMS rated power	16 W
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Sustainability certificates	TCO
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Extron, Crestron (RS-232C only), Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol

Weight and Dimensions

Depth	395 mm
Width	356 mm
Height	133 mm
Weight	5800 g
Package depth	475 mm
Package width	442 mm
Package height	315 mm
Package weight	8797 g
