Copying Menu Settings Between Projectors (Batch Setup)
247
After selecting the projector's menu settings for one projector, you can use the
following methods to copy the settings to other projectors, as long as they are
the same model.
by using a USB flash drive
by connecting a computer and projector using a USB cable
by using Epson Projector Management
You cannot copy any information unique to an individual projector, such as
Light Source Hours or Status.
a
Perform batch setup before adjusting the image settings such as
keystone distortion correction. Since image adjustment values are
also copied to another projector, the adjustments you made before
performing the batch setup are overwritten and the projected screen
you adjusted may change.
When copying the menu settings from one projector to another,
user's logo is also copied. Do not register the information that you do
not want to share between multiple projectors as a user's logo.
Make sure Batch Setup Range is set to Limited if you do not want to
copy the following settings:
Password Protection settings
EDID in the Signal I/O menu
Network menu settings
s Management > Batch Setup Range
Caution
Epson takes no responsibility for batch setup failures and associated repair costs
due to power outages, communication errors, or other problems that may cause
such failures.
gg Related Links
"Transferring Settings From a USB Flash Drive" p.247
"Transferring Settings From a Computer" p.248
Transferring Settings From a USB Flash Drive
You can copy menu settings from one projector to another of the same model
using a USB flash drive.
a
The USB flash drive must use a FAT format and not incorporate any
security function. Delete any files on the drive before using it for batch
setup or the settings may not be saved correctly.
a
Disconnect the power cord from the projector, and check that all of the
projector's indicators have turned off.
b
Connect an empty USB flash drive directly to the projector's USB-A
port.
c
Hold down the [Esc] button on the remote control or the control panel
and connect the power cord to the projector.
d
When all of the projector's indicators turn on, release the [Esc] button.
The indicators start flashing and the batch setup file is written to the
USB flash drive. When writing is finished, the projector turns off.
Caution
Do not disconnect the power cord or the USB flash drive from the projector
while the file is being written. If the power cord or USB flash drive is
disconnected, the projector may not start correctly.
e
Remove the USB flash drive.
a
The file name for the batch setup file is PJCONFDATA.bin. If
you need to change the file name, add text after PJCONFDATA
using only alphanumeric characters. If you change the
PJCONFDATA section of the file name, the projector may not be
able to recognize the file correctly.
