Epson EB-735Fi User Manual

Contents
6
Projector Interactive Settings - Interactive Menu ...................... 238
Interactive Menu - Print Menu............................................................................................... 238
Interactive Menu - Save Menu............................................................................................... 239
Interactive Menu - Mail Menu................................................................................................ 240
Interactive Menu - Directory Menu...................................................................................... 240
Multiple Projector Operation Settings - Multi-Projection
Menu ............................................................................................... 242
Image Quality Memory Settings - Memory Menu....................... 244
Projector Setup Settings - ECO Menu .......................................... 245
Projector Initial Settings and Reset Options - Initial/All
Settings Menu ................................................................................ 246
Copying Menu Settings Between Projectors (Batch Setup) ...... 247
Transferring Settings From a USB Flash Drive ................................................................. 247
Transferring Settings From a Computer ............................................................................ 248
Batch Setup Error Notification ......................................................................................... 249
Maintaining the Projector 250
Projector Maintenance .................................................................. 251
Cleaning the Projection Window.................................................. 252
Cleaning the Obstacle Sensor....................................................... 253
Cleaning the Projector Case.......................................................... 254
Air Filter and Vent Maintenance .................................................. 255
Cleaning the Air Filter ............................................................................................................... 255
Replacing the Air Filter ............................................................................................................. 256
Replacing the Interactive Pen Tip ................................................ 259
Replacing the Soft Pen Tip...................................................................................................... 259
Replacing the Soft Pen Tip with the Hard Pen Tip......................................................... 260
Updating the Firmware ................................................................. 261
Updating Firmware Using a USB Storage Device........................................................... 261
Updating Firmware Using a Computer and USB Cable ............................................... 262
Solving Problems 264
Projection Problems ...................................................................... 265
Projector Indicator Status ............................................................. 266
Solving Image or Sound Problems............................................... 269
Solutions When No Image Appears..................................................................................... 269
Solutions When Image is Incorrect Using the USB Display Function ..................... 269
Solutions When "No Signal" Message Appears............................................................... 270
Displaying From a Windows Laptop.............................................................................. 270
Displaying From a Mac Laptop........................................................................................ 270
Solutions When "Not Supported" Message Appears .................................................... 271
Solutions When Only a Partial Image Appears................................................................ 271
Solutions When the Image is not Rectangular................................................................ 271
Solutions When the Image Contains Noise or Static..................................................... 272
Solutions When the Image is Fuzzy or Blurry .................................................................. 272
Solutions When the Image Brightness or Colors are Incorrect ................................. 273
Solutions When an Afterimage Remains on the Projected Image .......................... 273
Solutions to Sound Problems................................................................................................. 273
Solutions to Microphone Problems ..................................................................................... 274
Solutions When Image File Names are not Displayed Correctly in PC Free......... 274
Solving Projector or Remote Control Operation Problems....... 275
Solutions to Projector Power or Shut-Off Problems...................................................... 275
Solutions to Problems with the Remote Control............................................................ 275
Solutions to Password Problems........................................................................................... 276
Solution When "The Battery that Saves Your Clock Settings is Running Low"
Message Appears........................................................................................................................ 276
Solving Interactive Features Problems........................................ 277
Solutions When "Error Occurred in the Easy Interactive Function" Message
Appears........................................................................................................................................... 277
Solutions When the Interactive Pens do not Work........................................................ 277
Solutions When You Cannot Operate a Computer from the Projected Screen . 278

Epson EB-735Fi Specifications

General

Matrix size	0.61 \
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	- m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 100 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	2500 ANSI lumens
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Focus	Manual
Throw ratio	0.26 - 0.36:1
Fixed focal length	3.7 mm
3D	No
Full HD	Yes
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
Audio (L/R) out	1
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	36 dB
Country of origin	China
Interactive input supported	Interactive pen/Touch
Noise level (economic mode)	26 dB
Cables included	AC
Bundled software	Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projektor Management
Storage temperature (T-T)	-10 - 60 °C
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	255 W
Power consumption (economy mode)	197 W
Placement	Ceiling, Wall
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
RMS rated power	16 W
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Sustainability certificates	TCO
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Extron, Crestron (RS-232C only), Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol

Weight and Dimensions

Depth	395 mm
Width	356 mm
Height	133 mm
Weight	5800 g
Package depth	475 mm
Package width	442 mm
Package height	315 mm
Package weight	8797 g
