Epson EB-S02 Service Manual

EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Disassembly and Assembly CONFIDENTIAL
SEIKO EPSON 116 Revision C
3.6 Reference (Part Names given in the SPI)
Part names used in this chapter are rewritten so as to be read easily in sentences. The
part names used in this manual and the corresponding official names given in SPI are
listed below.
PART NAMES GIVEN IN THE SPI
Names used in this Chapter Official Name given in SPI
3LCD Logo Plate LOGO PLATE, 3LCD;W
Air Filter AIR FILTER ASSY
Air Filter Cover COVER,AIR FILTER;BW
Air Filter Cover Band BAND,COVER,AIRFILTER
Auto Iris AUTO IRIS ASSY;AS
BA Cable CABLE,PS_BALLAST
BA Insulation Sheet SHEET,INSULATION,BALLAST
BA Lamp Cable CABLE,BALLAST LAMP;2
BA Shield Plate SHIELD PLATE,BALLAST
BA Unit BALLAST UNIT
EMC Sheet SHEET,EMC
EX Fan FAN,EXHAUST
EX Fan Holder HOLDER,FAN,EXHAUST
EX Louver louver,ex;W
FB Insulation Sheet SHEET,INSULATION,FB
Focus Ring FOCUS RING
Foot Rubber FOOT RUBBER
Front Foot FOOT UNIT,FRONT;B
Front Slit SLIT,FRONT;BB
HK Assy HK ASSY
HK GND Plate PLATE,GND,HK
IF Case CASE,IF;1B
IF Shade Case CASE,SHADE,IF
Inner EX Duct DUCT,EXHAUST INNER
INT Duct DUCT,INTAKE
INT Fan FAN,INTAKE
INT Fan Cushion CUSHION,INTAKE FAN;A
IR Board PWB ASSEMBLY;IR_S2
Kensington Shade Sheet SHEET,SHADE,KENSINGTON
Lamp LAMP ASSY;AS
Lamp Connector Holder HOLDER,CONNECTOR,LAMP
Lamp Cover LID ASSY,LAMP;BWB
Lamp Fan FAN,LAMP
LED Lens LENS,LED
Lens Shutter SHUTTER,LENS;BB
Lower Case CASE,LOWER;WW
Lower Sheet SHEET,LOWER
Lower Shield Plate SHIELD PLATE,LOWER
LV Duct DUCT,LV
LV Duct 2 DUCT,LV;2
LV Duct Cover COVER,DUCT,LV
MA Board BOARD MA ASSY;1W;AS
MA Insulation Sheet SHEET,INSULATION,MA
MA Plate PLATE,MA;1
MA Shield Plate SHIELD PLATE,MA
Model Plate MODEL NAME PLATE;EB-W12
Optical Engine Optical Engine;AS
PS Case CASE,PS
PS Duct DUCT,PS
PS Filter PS FILTER ASSY;AS
PS Insulation Sheet SHEET,INSULATION,PS
Names used in this Chapter Official Name given in SPI

Epson EB-S02 Specifications

General

Matrix size	0.55 \
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 350 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 30 °
Projector brightness (economic mode)	2080 ANSI lumens
Focus	Manual
Offset	8:1 %
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Focal length range	- mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN (RJ-45) ports	0
Full HD	Yes
Supported video modes	1080i
Supported graphics resolutions	1920 x 1080 (HD 1080), 800 x 600 (SVGA)
RMS rated power	1 W
Placement	Desktop
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Power source	AC
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Noise level	37 dB
Country of origin	China
Noise level (economic mode)	29 dB
Pallet width	800 mm
Pallet height	2204 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	360 mm
Package width	335 mm
Package height	158 mm
Package weight	3320 g
