Epson EB-S02 Service Manual

EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Troubleshooting CONFIDENTIAL
SEIKO EPSON 41 Revision C
TROUBLESHOOTING ON OPERATION ABNORMALITY
Error Status Faulty part/part name Cause Remedy Reference
Operation using Remote
Controller cannot be made.
Remote Controller
Batteries have run out. Replace the batteries with new ones. ---
Remote Controller is broken. Replace Remote Controller. ---
RC Filter RC Filter is dirty. Clean RC Filter. If not improved, replace RC Filter.
"3.3.6 MA Board
(assembly) (p74)"
IR Board IR Board is broken. Replace IR Board.
• "2.4.6 Cable
Connection and
Projector’s Status
(p46)"
• "3.3.6 MA Board
(assembly) (p74)"
• "3.3.12.1 IR Board
(p97)"
RC Cable
Cable is not connected properly. Connect the cable between IR Board and MA Board correctly.
Cable is broken. Replace the cable.
MA Board
Elements for remote control on MA
Board are broken.
If the error continues after carrying out the remedies above, the
related circuit on MA Board is broken, so replace MA Board.
"3.3.6 MA Board
(assembly) (p74)"
Operation using Control Panel
cannot be made.
SW Board SW Board is broken. Replace SW Board.
• "2.4.6 Cable
Connection and
Projector’s Status
(p46)"
• "3.3.6 MA Board
(assembly) (p74)"
• "3.3.5.1 SW Board
(p67)"
 SW Button
 SW Selection Button
SW Button or SW Selection Button is
not fixed properly or broken.
Re-assemble the SW Button or SW Selection Button. Replace it if
it is broken.
SW Cable
Cable is not connected properly. Connect the cable correctly.
Cable is broken. Replace the cable.
MA Board
Elements for operation control on MA
Board are broken.
If the error continues after carrying out the remedies above, the
related circuit on MA Board is broken, so replace MA Board.
"3.3.6 MA Board
(assembly) (p74)"
LED does not light.
(Power can turn on.)
SW Board SW Board is broken. Replace SW Board.
• "2.4.6 Cable
Connection and
Projector’s Status
(p46)"
• "3.3.6 MA Board
(assembly) (p74)"
• "3.3.5.1 SW Board
(p67)"
SW Cable
Cable is not connected properly. Connect the cable correctly.
Cable is broken Replace the cable.
MA Board
Elements for LED display on MA
Board are broken.
If the error continues after carrying out the remedies above, the
related circuit on MA Board is broken, so replace MA Board.
"3.3.6 MA Board
(assembly) (p74)"

Epson EB-S02 Specifications

General

Matrix size	0.55 \
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 350 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 30 °
Projector brightness (economic mode)	2080 ANSI lumens
Focus	Manual
Offset	8:1 %
Throw ratio	1.45 - 1.96:1
Digital zoom	1.35 x
Focal length range	- mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN (RJ-45) ports	0
Full HD	Yes
Supported video modes	1080i
Supported graphics resolutions	1920 x 1080 (HD 1080), 800 x 600 (SVGA)
RMS rated power	1 W
Placement	Desktop
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Power source	AC
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Noise level	37 dB
Country of origin	China
Noise level (economic mode)	29 dB
Pallet width	800 mm
Pallet height	2204 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	360 mm
Package width	335 mm
Package height	158 mm
Package weight	3320 g
