40
Adjusting the Image Height
If you are projecting from a table or other flat surface and the image is too
A
Extend the rear foot
high or low, you can adjust the image height using the projector's adjustable
B
Retract the rear foot
feet. The larger the angle of tilt, the harder it becomes to focus. Locate the
projector so that it only needs to be tilted at a small angle.
If the projected image is unevenly rectangular, you need to adjust the image
a
Turn on the projector and display an image.
shape.
b
To adjust the front foot, pull up on the foot release lever and lift the
gg Related Links
front of the projector.
"Image Shape" p.41
The foot extends from the projector. You can adjust the position up to
12 degrees.
c
Release the lever to lock the foot.
d
If the image is tilted, rotate the rear feet to adjust their height.
