a
If the [Esc] button is held down for about two seconds while
the corner selection screen from step 4 is displayed, the
following screen is displayed.
Reset Quick Corner: Resets the result of Quick Corner
corrections.
Switch to H/V-Keystone: Switches the correction method to
H/V-Keystone.
s "Settings Menu" p.70
Adjusting the Image Size
EB-X14/EB-W12/EB-X12/EB-X11
Turn the zoom ring to adjust the size of the projected image.
EB-S12/EB-S11
Adjust by using the [Wide]/[Tele] buttons on the control panel.
Wide: Enlarges the size of the projected image.
Tele: Reduces the size of the projected image.
Adjusting the Image Position
Press the foot adjust lever to extend and retract the front adjustable foot.
You can adjust the position of the image by tilting the projector up to 12
degrees.
a
The larger the angle of tilt, the harder it becomes to focus. Install the
projector so that it only needs to be tilted at a small angle.
Adjusting Projected Images
40
