Printer Basics
Part Names and Functions
A
Control panel Allows you to operate the printer and indicates the printer's status.
B
Printer cover Open to rell the ink tank or to remove jammed paper.
C
Ink tank cover Open to rell the ink tank.
D
Ink tank cap
E
Ink tank Contains black ink and is located on the print head.
F
front cover Open when removing jammed paper.
G
Paper cassette cover Open to load paper in the paper cassette.
A
feeder guard Prevents foreign substances from entering the printer. This cover should
usually be closed.
User's Guide
Printer Basics
11
