Epson EH-TW6100W User Manual

Troubleshooting
81
"Not supported" is displayed
Check Remedy
Is the image signal format setting correct? When Video is input
If nothing is projected even when Video Signal is set to Auto
from the configuration menu, set the signal that matches the
connected device.
s Extended - Input Signal - Video Sig-
nal p.73
When Component is input
If nothing is projected even when Component is set to Auto
from the configuration menu, set the signal that matches the
connected device.
s Extended - Input Signal - Compo-
nent p.73
(Only when projecting computer image sig-
nals)
Do the image signal's frequency and resolu-
tion correspond to the mode?
Check the image signal being input in Resolution from the con-
figuration menu, and check that it corresponds to the projector's
resolution.
s p.96
"No Signal" is displayed
Check Remedy
Are the cables connected correctly?Check that all the cables required for projection are securely
connected.
s p.18
Is the correct image input port selected? Change the image with the source buttons on the remote con-
trol, or the
button on the control panel. s p.23
Is the connected device turned on? Turn on the device.
(Only when projecting computer image sig-
nals)
Are the image signals being output to the
projector?
Change it so that the image signal is set to external output, and
not just the computer's LCD monitor. For some models, when
the image signals are output externally, they no longer appear
on the LCD monitor.
For the computer's specifications, see the documentation sup-
plied with the computer.
If the connection is made while the power of the projector or the
computer is already turned on, the Fn key (Function key) that
changes the computer's image signal to external output may not
work. Turn the power for the computer and the projector off and
then back on again.
Images are fuzzy or out of focus
Check Remedy
Has the focus been adjusted? Adjust the focus. s p.25
Is the lens cover attached? Remove the lens cover.
Is the projector at the correct distance? Check the recommended projection range.
s p.17

Epson EH-TW6100W Specifications

General

Aspect ratio	16:9
RS-232 ports	1
Matrix size	0.61 \
White light output	2300 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.4 - 14.5 m
Projection distance (wide)	0.9 - 8.9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	18 - 29 mm
Aperture range (F-F)	1.51 - 1.99
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Noise level	32 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	24 dB
RMS rated power	20 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	358 W
Power consumption (economy mode)	274 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, HDMI
Pallet width	800 mm
Pallet height	2010 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)

Weight and Dimensions

Depth	365 mm
Width	420 mm
Height	137 mm
Weight	6000 g
Package depth	495 mm
Package width	435 mm
Package height	310 mm
Package weight	9720 g
