Epson EH-TW6100W User Manual

Troubleshooting
84
Problems when projection starts
The projector does not turn on
Check Remedy
Is the power turned on?
Press the
button on the remote control or the button
on the control panel.
Is Child Lock set to On? When Child Lock is set to On from the configuration menu, hold
down the
button on the control panel for approximately
three seconds, or perform operations from the remote control.
s Settings - Lock Setting - Child Lock p.71
Is Control Panel Lock set to On?If Control Panel Lock is set to On from the configuration menu,
all of the control panel buttons except for
button are disa-
bled. Perform operations from the remote control.
s Settings
- Lock Setting - Control Panel Lock p.71
Are the indicators switched off? Disconnect and then reconnect the projector's power cable.
Check that power is being supplied.
Do the indicators turn on and off when the
power cable is touched?
Turn off the projector, and then disconnect and reconnect the
projector's power cable. If the problem continues, stop using the
projector, remove the power plug from the electrical outlet, and
contact your local dealer or the nearest projector information
center.
s Epson Projector Contact List
Problems with the remote control
The remote control does not respond
Check Remedy
Is the remote control light-emitting area
pointing towards the remote receiver on the
projector during operation?
Point the remote control towards the remote receiver. Also,
check the operating range.
s p.21
Is the remote control too far from the projec-
tor?
Check the operating range.
s p.21
Is direct sunlight or strong light from fluores-
cent lamps shining onto the remote receiver?
Set the projector up in a location where strong light does not
shine onto the remote receiver.
Are the batteries dead or have the batteries
been inserted correctly?
Make sure the batteries are inserted correctly or replace the bat-
teries with new ones if necessary.
s p.21
Is the remote control pointed at the Wire-
lessHD Transmitter when operating the WiHD
Transmitter control button? (EH-TW6100W
only)
Make sure you point the remote control at the WirelessHD Trans-
mitter when using the WiHD Transmitter control button on the
remote control.
s p.55

Epson EH-TW6100W Specifications

General

Aspect ratio	16:9
RS-232 ports	1
Matrix size	0.61 \
White light output	2300 ANSI lumens
Projection distance	- m
Projection technology	3LCD
Screen size compatibility	30 - 300 \
Projection distance (tele)	1.4 - 14.5 m
Projection distance (wide)	0.9 - 8.9 m
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Full HD	Yes
Color modes (2D)	Dynamic, Cinema
Supported 3D formats	Side by side, Top and bottom, Frame packing
Analog signal format system	-
Focus	Manual
Focal length range	18 - 29 mm
Aperture range (F-F)	1.51 - 1.99
Lamp type	E-TORL
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Noise level	32 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	24 dB
RMS rated power	20 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	358 W
Power consumption (economy mode)	274 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Cables included	AC, HDMI
Pallet width	800 mm
Pallet height	2010 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)

Weight and Dimensions

Depth	365 mm
Width	420 mm
Height	137 mm
Weight	6000 g
Package depth	495 mm
Package width	435 mm
Package height	310 mm
Package weight	9720 g
