Introduction
9
Buttons (Indicators) Function
f
Top/Bottom
•
Selects menu items or adjustment values while displaying the projector's menu.
s p.58
•
Adjusts keystone distortion in projected images. s p.30
g
[Esc]
Returns to the previous menu level when a menu is displayed.
s p.58
h
[Enter]
When a menu is displayed, it confirms the current item and moves to the next
level.
s p.58
i
[Menu]
Displays and closes the Configuration menu.
On the Configuration menu, you can make adjustments and settings for Sig-
nal, Image, and so on.
s p.58
j
(Temperature indicator)
Flashes orange if the internal temperature is too high. Shows the projector's
errors through a combination of other indicators lit and flashing.
s p.71
c
When the Illumination function is set to Off, all indicators are off under normal projection conditions.
s
Extended - Operation - Illumination p.65
