Preparing
18
D : Lens center movement distance when the projector is moved (when lens shift is set to maximum right)
E : Projection distance from the projector to the screen
F : Size of the projected image
Unit: cm
16:9 Screen Size Projection Distance (E) Lens Shift Maximum Values
*
F W x H Minimum
(Wide)
Maximum
(Tele)
Distance
(A)
Distance
(B)
Distance
(C, D)
40" 89 x 50 116 189 5 55 21
60" 133 x 75 175 285 7 82 32
80" 177 x 100 235 381 10 110 43
100" 221 x 125 295 477 12 137 53
120" 266 x 149 354 574 15 164 64
150" 332 x 187 444 718 19 205 80
200" 443 x 249 593 958 25 274 106
*
Vertical and horizontal lens shift cannot both be set to their maximum values. s p.29
