Maintenance

Use the buttons to

select the color you want to adjust,

and then use the

buttons to

adjust.

Press the button to weaken the color

tone. Press the

button to strengthen

the color tone.

Return to step 5 and adjust each level.

To complete the adjustment, press the

button.
