Epson Expression 1680 Product Information

EPSON Expression 1680
8 - EPSON Expression 1680
1/01
Stopping a Scan in Progress
You can stop a scan in progress from either the client
computer or the scanner server.
❏ To cancel a scan from the client computer, click the Cancel
button on the Progress bar.
❏ To cancel from the scanner server, click the Cancel button
at the bottom of the EPSON Scan Server dialog box.
❏ To break the connection between the client computer and
the scanner server, click the Stop button on the EPSON
Scan Server dialog box. This closes EPSON TWAIN Pro
Network on the client computer and allows other client
computers to connect to the scanner server.
Related Documentation
CPD-11741 EPSON Expression 1680 User’s Guide
EPSON Expression 1680 Software
Reference Guide (html)
TM-EXP1680 EPSON Expression 1680 Service Manual
PL-EXP1680 EPSON Expression 1680 Parts Price List

Epson Expression 1680 Specifications

Scanning Specifications

optical resolution	1600 x 3200 dpi
maximum resolution	13, 600 x 18, 720 dpi with interpolation
effective pixels	13, 600 x 18, 720 pixels (1600 dpi)
color depth	48 bits per pixel internal/external
grayscale depth	16 bits per pixel internal/external
scanning speed (color, 1600 dpi, draft mode)	9.2 msec/line (approx.)
scanning speed (grayscale/monochrome, 1600 dpi, draft mode)	3.1 msec/line (approx.)

Operating Environment

temperature operating range	41ºF to 95ºF (5ºC to 35ºC)
humidity operating range	10% to 80% (no condensation)
humidity storage range	10% to 85% (no condensation)

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption (operating without optional unit)	60W
power consumption (operating with optional unit)	75W
power consumption (standby without optional unit)	10W

Weight and Dimensions

maximum read area	8.5" x 11.7" (216mm x 297mm)
width	13.1" (332mm)
depth	22.1" (562mm)
height	5.2" (133mm)
weight	18.7 lb (8.5 kg approx.)
