Remove only the yellow tape.

Important:

Do not touch the sections shown in the illustration. Doing so may prevent normal operation and printing.

Open the scanner unit with the document cover closed.

Replacing Ink Cartridges and Other Consumables

Replacing Ink Cartridges

118

Main Page
