4
■ Unplug the scanner and the AC adapter, and refer servicing to qualified service personnel
under the following conditions: The power cord or plug is damaged; liquid has entered the
scanner or the AC adapter; the scanner or the AC adapter has been dropped or the case
damaged; the scanner or AC adapter does not operate normally or exhibits a distinct change in
performance. (Do not adjust controls that are not covered by operating instructions.)
■ If you are not going to use the scanner for a long period, be sure to unplug the AC adapter
from the electrical outlet.
■ The lamp(s) in this product contain mercury. Please consult your state and local
regulations regarding disposal or recycling. Do not put in the trash.
Specifications
General
Scanner type Flatbed, color
Photoelectric device Color CCD line sensor
Effective pixels 10,200 × 14,040 pixels
Document size Flatbed: 8.5 × 11.7 inches (216 × 297 mm), US letter or A4 size
ADF: 8.5 × 14 inches (216 × 356 mm)
ADF paper input Face-up loading
ADF paper output Face-down ejection
ADF paper capacity 50 sheets of 75 g/m
2
paper
Maximum total thickness under 0.2 inch (5 mm)
Paper types Bond paper, fine-quality paper, check paper, and recycled paper
Scanning resolution 1200 dpi (main scan)
1200 dpi with Micro Step Drive
™
(subscan)
Output resolution 50 to 4800, 7200, and 9600 dpi
(50 to 9600 dpi in 1 dpi increments)
Scanning Speed 300 dpi B/W: 0.4 msec per line
300 dpi Color: 1.2 msec per line
Image data 16 bits per pixel per color internal
16 bits per pixel per color external (maximum)
Interface One USB port
One optional network card slot
Light source White cold cathode fluorescent lamp
Mechanical
Dimensions Width: 18.4 inches (468 mm)
Depth: 15.6 inches (395 mm)
Height: 7.9 inches (200 mm)
Weight Approx. 22 lb (10 kg)
