Board Interfaces and Connectors
Epson IMU_OEM7 Interposer Board Seiko Epson Corporation 7
User Manual (Rev. 1.3)
6.2. Epson G Series IMU Connector P2
The EIIB provides a 2x10 1 mm pitch socket connector P2 (Samtec CLM-1100-2-L-D) for directly
mounting the Epson G series IMU (M-G320, M-G354 or M-G364). There are two diagonal mounting
holes to secure the IMU to the EIIB. The recommended fastening hardware for these mounting holes
are SEMS M2-14 stainless steel screw and M2 stainless steel hex nut or equivalent.
The P2 connector silk screen and mounting holes provides a guide as to the correction mounting
orientation of the Epson IMU.
NOTE: Take precaution to ensure the supported Epson IMU is mounted correctly on P2, or else it may
cause permanent damage to the IMU, EIIB, or OEM7 Development Kit.
NOTE: If using Epson G series IMU on P2, do not mount an Epson V series IMU on P3.
Table 6.2 Epson G Series IMU Connector P2
Pin Number
Signal Name
Description / Comment
1
SPI_CLK
SPI Clock (Supports SPI Mode 3 only)
2
SPI_MISO
SPI Master In Slave Out (Supports SPI Mode 3 only)
3, 4, 8, 15
GND
Circuit ground
5
SPI_MOSI
SPI Master Out Slave In (Supports SPI Mode 3 only)
6
SPI_nCS
SPI Chip select (Supports SPI Mode 3 only)
7
IMU_UART_TXDO
For internal debug purpose only
9
IMU_UART_RXDI
For internal debug purpose only. Pulled to VCC with 10K ohm.
10, 11, 12
3.3V
3.3V supplied by OEM7 Development Kit
13
IMU_GPIO1_DRDY
IMU Data Ready Output (connects to OEM7 EVENT_IN2 signal)
14
GPIO2_EXT
IMU signal that can be optionally connected to:
- OEM7 TIMEMARK (R1)
- OEM7 EVENT_OUT2 (R2)
NOTE: Do not mount both R1 and R2 at the same time.
Refer to Section Error! Reference source not found. Error! Re
ference source not found. for more information.
16
IMU_nRESET
Connected to RC delay network on the board
17, 18, 19, 20
—
Not connected
