Disassembly/Reassembly Overview 9
L200/L201/L100/L101 Revision A
1.1 Overview
This chapter describes procedures for disassembling the main parts/units of L200/L201/L100/L101. Unless
otherwise specified, disassembled parts/units can be reassembled by reversing the disassembly procedure. See
the cautions or tips for disassembly/reassembly described in “ 1.3 Details of Disassembling/Reassembling by
Parts/Unit (p23)”.
Read the following before disassembling and reassembling.
 “ Safety Precautions (p3)”
 “ 1.1.2 Checks and precautions before disassembling (p10)”
When you have to remove units or parts that are not described in this chapter, see the exploded diagrams of SPI
(Service Parts Information).
1.1.1 Tools
Use only specified tools to avoid damaging the printer.
Note *: All of the tools listed above are commercially available.
EPSON provides the tools listed with EPSON part code.
Table 1-1. Tools
Name EPSON Part Code*
(+) Phillips screwdriver #1 1080530
(+) Phillips screwdriver #2 ---
Flathead screwdriver ---
Flathead Precision screwdriver #1 ---
Tweezers ---
Longnose pliers ---
Acetate tape 1003963
Nippers ---

Epson L100 Specifications

General

Print Technology	On-demand inkjet (Piezoelectric)
Print Resolution	5760 x 1440 dpi
Ink Type	Dye Ink
Minimum Ink Droplet Size	3 pl
Print Speed (Black)	27 ppm (Draft)
Print Speed (Color)	15 ppm (Draft)
Connectivity	USB 2.0
Paper Capacity	100 sheets
Weight	2.7 kg
Ink System	4-color (Cyan, Magenta, Yellow, Black)
Ink Bottle Capacity	70 ml per color
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Operating Systems Supported	Windows XP, Windows Vista, Windows 7, Mac OS X 10.5.8 or later
Dimensions	472‎ x 222 x 130 mm (Width x Depth x Height)
