2.2.1 Disassembly Flowchart
L350/L300/L355/L210/L110 Series described in this manual have differences in their structure because the same
printer mechanism is used for some of them and the composition of housings or functions differs.
The functions and differences according to the models are as follows.
Therefore, parts and units are colored and classified into 5 types in the flowchart given in this section.

Common parts/unit: Black
 L350/L355/L210 Series: Blue
 L355 Series: Red
 L300/L110 Series: Green
 L210/L110 Series: Orange
Table 2-2. Function List According to Models
Item L350 Series L355 Series L210 Series L300 Series L110 Series
Scanner O O O --- ---
Panel
Movable type --- O --- --- ---
Locked type O --- O --- ---
Button type --- --- --- O O
Wireless LAN --- O --- --- ---
Low cost parts --- --- O --- O
Disassembly Flowchart Start Position p 32 p 32 p 32 p 33 p 33
Table 2-3. Components According to Functions
Item Specification
Scanner
The shape and unit of components below differ due to the difference of specifications of Scanner Unit.
•Scanner Unit
• Hinge
• Housing Rear/Left/Right
• Main Board
• Shield Plate
Panel
The shape and unit of components below differ due to the difference of specifications of Panel Unit.
• Panel Unit
Wireless LAN
The following part is not mounted on the models without the Wireless LAN.
• Wireless LAN Module
Low cost parts
• CR Timing Belt
• CR Motor
•PF Motor
• Housings, others

Epson L350 Specifications

General

Print Technology	Inkjet
Print Method	On-demand inkjet (Piezoelectric)
Print Resolution	5760 x 1440 dpi
Minimum Ink Droplet Size	3 pl
Functions	Print, Copy, Scan
Scanner Type	Flatbed color image scanner
Output Tray Capacity	30 sheets
Connectivity	USB 2.0
Ink Colors	Black, Cyan, Magenta, Yellow
Weight	4.4 kg
Ink Tank System	Integrated Ink Tank System
Print Speed (Black)	33 ppm
Print Speed (Color)	15 ppm
Scan Resolution	600 x 1200 dpi
Paper Sizes	A4, A5, A6, B5, Letter, Legal, DL
Input Tray Capacity	100 sheets
Operating System Compatibility	Windows XP, Windows 7, Windows 8, Windows Vista, Mac OS X 10.5.8 or later
Dimensions	472 x 300 x 145 mm
