Disassembly/Reassembly Overview 24
L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series Revision A
Ink Supply Tank (Cyan) 4:11 --- 4:11
Ink Supply Tank (Black)
4:11 --- 4:11
Ink Supply Tank Tube Assy
3:30 --- 3:30
Tube Guide Sheet Sub
0:30 --- 0:30
Tube Pressing Plate
0:52 --- 0:52
Ink Supply Tube Guide 1st
0:06 --- 0:06
Ink Supply Tube Guide 2nd
3:25 --- 3:25
Joint
2:20 --- 2:20
Adapter Cover
0:37 --- 0:37
Ink Supply Tube Assy
2:11 --- 2:11
Tube Guide Sheet
1:39 --- 1:39
Adapter
1:49 --- 1:49
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total
