Epson LX-300 Manual

Epson LX-300+II
7/06 Epson LX-300+II - 9
To switch back to continuous paper, follow these steps:
1. Press the
Load/Eject button to eject any sheet in the
printer.
2. Move the paper release lever to the continuous paper
position.
3. Press the
LF/FF button to load the paper on the tractor.
Printing with the pull tractor
To load continuous paper using the pull tractor, you must move
the tractor to the pull tractor position, as described below. If
your tractor is already installed in this position, make sure the
printer is turned off and skip to step 6.
1. Turn off the printer; then remove the printer cover and the
paper guide.
2. Remove the paper tension unit by gently squeezing the lock
tabs and pulling it out of the printer.
3. Pull the paper release lever forward to the continuous paper
position.
4. To remove the tractor from the push position, gently
squeeze the lock tabs on both sides and then rotate the
tractor up to pull it away from the printer.
5. Lower the tractor onto the mounting slots at the top of the
printer as shown below, and tilt it back until you feel it lock
into place.
6. Unlock the sprockets by pulling the blue lock levers
forward.
7. Feed the paper into the rear paper slot as shown below, and
pull it up. Position the paper using the scale on the printer
as a guide. Printing starts to the right of the position marked
0 (under the paper now).

Epson LX-300 Specifications

General

Print Method	9-pin impact dot matrix
Interface	Parallel
Paper Handling	Friction feed, tractor feed
Weight	4.4 kg
Operating Environment	Temperature: 5 - 35°C, Humidity: 10 - 80%
